4. Install the dongle in the internal USB port on the lower I/O assembly. Carefully close the
workstation and maneuver it to an upright position.
Figure 3-13 Internal USB port
IMPORTANT: An outline around the internal USB port identifies the maximum area allowed for
an internal USB device. The dongle must fit within this area.
5. Ensure the mouse and keyboard are within 30 cm (12 in) of the workstation and away from
interference from other devices. Turn on the power on the bottom of the wireless mouse (1) Place
them in front of the workstation.
Figure 3-14 Wireless keyboard and mouse
