HP Z240 SFF Workstation rear panel
1 Power cord connector 6 USB 3.0 ports (6) (blue)
2 Audio line-in connector (blue) 7 Serial port
3 RJ–45 network connector 8 DisplayPort (DP) (3)
4 PS/2 mouse connector (green) 9 PS/2 keyboard connector (purple)
5 Audio line-out connector (green)
NOTE: The labels for the rear panel connectors use industry-standard icons and colors.
NOTE:
The DP ports are not supported when the system is
congured with Intel® Xeon E3-12x0 v5 processors. For all other processors, these DP ports are
disabled by default when a discrete graphics card is installed.
NOTE:
Simultaneous usage of integrated Intel HD graphics and discrete graphics cards (in order to drive more than three displays) can be enabled using the
C
omputer (F10) Setup Utility. However, HP recommends using only discrete graphics cards when attaching four or more displays.
HP Z240 SFF Workstation components 3
