System cabling
SFF workstation system cabling
See System board components on page 5 to determine the location of system board connectors.
Cable To Cable designator on system board
PSU cable PCA (Main power) P1 (White)
PSU cable PCA (PWR COMM) P2 (White)
PSU cable PCA (CPU power) P3 (White)
SATA power cable PCA P160 (Black)
SATA power cable First ODD P12 (Black)
SATA power cable Other drive P13 (Black)
SATA power cable SSD P15 (Black)
SATA power cable First HDD P16 (Black)
Speaker PCA P6 (White)
Cooler fan cable PCA P8 (White)
System fan cable PCA P11 (Brown)
Front audio cable PCA P23 (Blue)
LED/Power button cable PCA P5 (Black)
Front USB 2.0 cable-1 PCA P24 (Yellow)
Front USB 3.0 cable-2 PCA P26 (Blue)
Serial cable PCA P52 (Black)
Chassis solenoid lock PCA P124 (Black)
Hood sensor PCA P125 (White)
SATA cable First HDD SATA0 (Blue)
SATA cable Second HDD SATA1 (Black)
SATA cable First ODD SATA2 (Black)
SATA cable Third HDD SATA3 (Black)
