Chassis components
The following gure shows the chassis components of a typical tower workstation layout. Drive
congurations can vary.
Item Description Item Description
1 Power supply 6 Slim optical drive
2 Side access panel 7 Hard drive
3 Cooler 8 Optional second optical drive
4 System board 9 Optional solid state drive
5 Chassis 10 Front bezel
10 Chapter 1 Hardware overview
