Technical white paper | HP Z640 Workstation
I/O slot options
In addition to the 32-bit/33 MHz full height and full length PCI slot, the HP Z640 provides a total of up to ve high-
performance graphics and I/O slots in single CPU conguration and up to four high-performance graphics and I/O slots in
Dual CPU conguration, including support for up to two PCIe 3.0 graphics cards in PCIe 3.0 x16 slots. The remaining PCIe
slots are open ended and can accommodate a variety of dierent cards and congurations.
Figure 3. I/O slot layout (single CPU conguration) Figure 4. I/O slot layout (dual CPU conguration)
Recipe for optimizing PCI-Express I/O performance
For high I/O bandwidth applications, the choice of slot loading, CPU, and memory conguration can be optimized to
ensure maximum bandwidth available. Applications and cards sensitive to I/O latency may benet as well from some of
the tips below.
Recommended conguration steps
1. Place Graphics and GPU cards rst, following the slot order listed in Table 3.
2. Place I/O cards next, from highest bandwidth to lowest, following the slot order listed in Table 3. This is the optimal
load order for most applications.
3. If PCIe 2.0 I/O cards fail to train at full Gen2 speeds (5 Gb/s) in Gen3 slots, then try slot 1 or slot 3 which only trains up
to PCIe Gen2.
4. Additional I/O bandwidth renements may be possible. If necessary, refer to the tips on following page.
Riser
Connector
PCIe2 x1
PCI32
PCIe2 x4
PCIe3 x8
Open ended, full height, half lengthSlot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Open ended, full height, full length (with extender)
Open ended, full height, full length (with extender)
PCIe3 x16
PCIe3 x16
Retention latch, full height, full length
(with extender)
Retention latch, full height, full length
(with extender)
32-bit/33 MHz, full height, full length (with extender)
CPU0
PCIe2 x 1
PCI32
PCIe2 x4
PCIe3 x8
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Open ended, full height, full length (with extender)
Open ended, full height, full length (with extender)
PCIe3 x16
PCIe3 x16
Retention latch, full height, full length
(with extender)
Retention latch, full height, full length
(with extender)
32-bit/33 MHz, full height, full length (with extender)
CPU0
Riser
Connector
CPU1
Slot 1

HP Z640 Specifications

General

Tcase	72.1 °C
Bus type	QPI
Stepping	R2
Processor cache	20 MB
Processor cores	8
Processor model	E5-2630V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	16
Processor codename	Haswell
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
Memory slots	4x DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	- GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Optical drive type	DVD±RW
Card reader integrated	No
Total storage capacity	256 GB
Discrete graphics card	Yes
On-board graphics card	-
Discrete graphics card model	NVIDIA® Quadro® K4200
Discrete graphics card memory	4 GB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Chassis type	Tower
Product color	Black
Country of origin	China
Placement supported	Vertical
Product type	Workstation
Motherboard chipset	Intel® C612
Power supply	925 W
HP segment	Business
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows 8.1 Pro
Scalability	2S
Processor code	SR206
Processor ARK ID	83356
Processor package size	52.5 x 45 mm
Supported instruction sets	AVX
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	464.8 mm
Width	175 mm
Height	444.5 mm
Weight	1500 g
