HP ZBook 15 G2

Item Component Spare part number
For use in South Korea 745663-AD1
For use in Spain 745663-071
For use in Sweden and Finland 745663-B71
For use in Switzerland 745663-BG1
For use in Taiwan 745663-AB1
For use in Thailand 745663-281
For use in Turkey
For use in Turkey F
745663-141
745663-541
For use in the United Kingdom and Singapore 745663-031
For use in the United States 745663-001
(4) Primary memory module (PC3L, 12800, 1600-MHz):
8-GB 693374-001
4-GB 691740-001
(5) Top cover (includes TouchPad, TouchPad cable, and TouchPad bracket) 734281-001
(6) Power button board (includes cable) 734285-001
(7) Function button board (includes cable and double-sided adhesive) 734284-001
(8) Fingerprint reader board (includes cable and double-sided adhesive) 734286-001
(9) ExpressCard assembly (includes activity LEDs and Thunderbolt port, Dual Mode
DisplayPort, and USB port)
794579-001
(10) Smart card reader (includes cable) 742159-001
(11) Audio/USB board (includes SD Card reader) 734288-001
(12) Fan/heat sink assembly (includes replacement thermal material):
For use only with an NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board, spare part
number 785223-001
734289-001
For use only with an NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board, spare part
number 785225-001
734290-001
For use only with an NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board, spare part
number 785224-001
734291-001
For use only with an AMD FirePro M5100 graphics board, spare part number 784470-001 784469-001
(13) Processor (includes replacement thermal material):
Intel Quad Core i7-4910MQ 2.90-GHz (SC turbo up to 3.90-GHz) processor (1600-MHz FSB,
8.0-MB L3 cache, 47 W)
778693-001
Intel Quad Core i7-4810MQ 2.80-GHz (SC turbo up to 3.80-GHz) processor (1600-MHz FSB,
6.0-MB L3 cache, 47 W)
778692-001
Intel Quad Core i7-4710MQ 2.50-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB,
6.0-MB L3 cache, 47 W)
773212-001
Intel Quad Core i7-4610M 3.00-GHz (SC turbo up to 3.70-GHz) processor (1600-MHz FSB,
4.0-MB L3 cache, 37 W)
765141-001
22 Chapter 3 Illustrated parts catalog
