Item Component Spare part number
Intel Dual Core i5-4340M 2.90-GHz (SC turbo up to 3.60-GHz) processor (1600-MHz FSB,
3.0-MB L3 cache, 37 W)
765142-001
Intel Dual Core i5-4210M 2.60-GHz (SC turbo up to 3.20-GHz) processor (1600-MHz FSB,
3.0-MB L3 cache, 37 W)
768420-001
(14) Graphics board (includes replacement thermal material):
NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board 785223-001
NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board 785225-001
NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board 785224-001
AMD FirePro M5100 graphics board 784470-001
(15) USB board (includes cable and double-sided adhesive) 734293-001
(16) Speakers (include cable) 734292-001
(17) RJ-45 (network) cable (included in the Cable Kit, spare part number 785222-001)
(18) Power connector cable (included in the Cable Kit, spare part number 785222-001)
(19) System board (includes battery connector bracket and replacement thermal material):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 or Windows 10 operating system
For use only on computer models equipped with an Intel Quad Core processor 784468-xxx
For use only on computer models equipped with an Intel Dual Core processor 784467-xxx
(20) Base enclosure (includes 4 rubber feet, battery lock latch, battery release latch, and RJ-45
cover)
785221-001
(21) Expansion memory modules (2, PC3L, 12800, 1600-MHz):
8-GB 693374-001
4-GB 691740-001
(22) Solid-state drive (SSD):
512-GB, SATA-3 795962-001
512-GB, Z Turbo Drive, PCIe 813138-001
512-GB, SATA-3, self-encrypting drive (SED), OPAL 2 813139-001
256-GB, SATA-3 795959-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 1 795960-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 2 795961-001
256-GB, M.2, PCIe 795955-001
240-GB, SATA-3 795958-001
180-GB, SATA-3 795957-001
128-GB, SATA-3 795956-001
Computer major components 23
