Display assembly
NOTE: The DreamVision display assembly is spared as a whole unit assembly only. The LED display
assembly is spared at the subcomponent level only. For more LED display assembly spare part information,
see the individual removal subsections.
Description Spare part number
15.6-in, FHD, UWVA, DreamVision display assembly equipped with a webcamera 735965-001
15.6-in, FHD, UWVA, DreamVision display assembly not equipped with a webcamera 735964-001
To remove the display assembly and access the LED display assembly subcomponents, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 37), and then remove the following components:
a. Service cover (see Service cover on page 38)
b. Hard drive (see Hard drive on page 39)
c. Optical drive (see Optical drive on page 41)
d. Keyboard (see Keyboard on page 50)
e. Top cover (see Top cover on page 58)
Remove the display assembly:
1. Close the computer.
2. Turn the computer upside down, with the rear toward you.
3. Make sure that the WWAN antenna cables are disconnected from the WWAN module (see WWAN module
on page 43).
4. Make sure that the WLAN antenna cables are disconnected from the WLAN module (see WLAN module
on page 46).
80 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
