HP ZR2440w User Manual

3 Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
NOTE: Be sure the master power switch, located on the rear panel of the monitor, is in the off
position. The master power switch turns off all power to the monitor.
Installing the Pedestal
NOTE: Do not install the pedestal if the monitor will be used on a wall, swing arm, or other mounting
fixture; instead see
Mounting the Monitor to User-Supplied Support Hardware on page 15 in this
chapter.
CAUTION: Whenever you handle the monitor, take care not to touch the surface of the LCD panel.
Pressure on the panel may cause non-uniformity of color or disorientation of the liquid crystals. If this
occurs the screen will not recover to its normal condition.
To assemble the ZR2040w, slide the pedestal upright into its base, as shown below.
Figure 3-1 Assembling the ZR2040w pedestal
6 Chapter 3 Setting Up the Monitor ENWW

HP ZR2440w Specifications

General

3D	No
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Response time	6 ms
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Viewable size diagonal	611.3 mm
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Digital vertical frequency	24 - 60 Hz
Digital horizontal frequency	24 - 80 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1200 (WUXGA)
HDCP	Yes
USB hub version	2.0
DVI-D ports quantity	1
USB Type-A downstream ports quantity	4
Ethernet LAN (RJ-45) ports	0
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	48 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	DisplayPort, DVI, USB
Certification	EPEAT Gold, CB, CE, FCC, ETLus, VCCI, C-tick, BSMI, TUV-S, ISO9241-307, TUV-GS, CCC, CECP, CEL, NOM, PSB, KC, GOST, ISC
Country of origin	China
Compliance industry standards	TCO 5.0
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	61 mm
Width (without stand)	562 mm
Height (without stand)	368 mm
Weight (without stand)	7600 g
