HP ZR2440w

Component Function
4 DVI-D Connector Connects the DVI-D cable to the monitor.
5 VGA Connector Connects the VGA cable to the monitor.
ZR2240w Model
Figure 3-4 ZR2240w Rear Components
2
2 1
2
3
2
4
2
5
2
6
2
7
8
9
11
11
10
10
Component Function
1 Cable Lock Provision Provides slot for use with cable security locks.
2 Master Power Switch Turns off all power to the monitor.
3 AC Power Connector Connects the AC power cord to the monitor.
4 DisplayPort Connector Connects the DisplayPort cable to the monitor.
5 HDMI Connector Connects an HDMI cable to the monitor.
6 DVI-D Connector Connects the DVI-D cable to the monitor.
8 Chapter 3 Setting Up the Monitor ENWW
