HP ZR2440w User Manual

ZR2440w Model
The default input on the ZR2440w is DisplayPort and the scan order is initially set to DisplayPort, DVI-D,
HDMI. You can change the current input, the default and the scan order through the OSD. Pressing the
+ button on the front of the monitor will take you directly to the OSD source-control submenu.
Figure 4-2 ZR2440w Front Panel Controls
Control Function
1
Menu Opens, selects or exits the OSD menu.
2
Minus If the OSD menu is on, press to navigate backward through
the OSD menu and decrease adjustment levels.
3
Plus/source If the OSD menu is on, press to navigate forward through
the OSD menu and increase adjustment levels.
If the OSD menu is inactive, press to activate the source
button that chooses the video signal input (VGA, DVI, or
DisplayPort).
4
OK
OK If the OSD menu is on, press to select the highlighted menu
item.
5
Power Turns the monitor on or off as long as the master power
switch on the rear panel is on.
6 Power LED Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
No light indicates power off, or normal operation if the LED
is suppressed.
ENWW
Overview of Operation
27

HP ZR2440w Specifications

General

3D	No
Pixel pitch	0.270 x 0.270 mm
Aspect ratio	16:10
Response time	6 ms
Display surface	Matt
Display diagonal	24 \
Display resolution	1920 x 1200 pixels
Viewable size diagonal	611.3 mm
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Digital vertical frequency	24 - 60 Hz
Digital horizontal frequency	24 - 80 kHz
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	1920 x 1200 (WUXGA)
HDCP	Yes
USB hub version	2.0
DVI-D ports quantity	1
USB Type-A downstream ports quantity	4
Ethernet LAN (RJ-45) ports	0
Tilt angle range	-5 - 35 °
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	48 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	DisplayPort, DVI, USB
Certification	EPEAT Gold, CB, CE, FCC, ETLus, VCCI, C-tick, BSMI, TUV-S, ISO9241-307, TUV-GS, CCC, CECP, CEL, NOM, PSB, KC, GOST, ISC
Country of origin	China
Compliance industry standards	TCO 5.0
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	61 mm
Width (without stand)	562 mm
Height (without stand)	368 mm
Weight (without stand)	7600 g
