ZR2740w Model

Figure 3-6 ZR2740w Rear Components

Component Function

1 Cable Lock Provision Provides slot for use with cable security locks.

2 Master Power Switch Turns off all power to the monitor.

3 AC Power Connector Connects the AC power cord to the monitor.

4 DisplayPort Connector Connects the DisplayPort cable to the monitor.

5 DVI-D Connector Connects the DVI-D cable to the monitor.

6 USB Upstream Connector Connects the monitor USB hub cable to a host USB port/

hub.

7 USB Downstream Connectors Connects optional USB devices to the monitor.

8 Information Card Provides information needed for a support call.

9 USB Downstream Connectors

(side panel)

Connects optional USB devices to the monitor.

ENWW

Rear Components
