HPE BladeSystem c7000 User Manual

8
Connection
Port
number
Connects to
interconnect
bay/port
Comments
Mezzanine
slot 1—4x
cards
4x port 1 3/Port N
• One
double-wide
interconnect
module
• Only port 1
of a two port
card will be
connected.
Mezzanine
1x/2x port 1
5 / port N
One or two
slot 2—1x or
1x/2x port 2
6 / port N
single-wide
2x cards
1x/2x port 3
1x/2x port 4
7 / port N
8 / port N
interconnect
modules
Mezzanine
slot 2—4x
cards
4x port 1
4x port 2
5/Port N
7/Port N
One or two
double-wide
interconnect
modules
* Connectivity to interconnect bays 7 and 8 is only available with
four-port mezzanine cards or port 2 of 4x card in Mezzanine slot 2.
Mapping full-height blades
The following table lists the available configurations for full-height
devices installed in device bay N (1–8).
* Connectivity to interconnect bays 7 and 8 is only available with
four-port mezzanine cards or port 2 of 4x card in Mezzanine slot 2.
Mapping BL2x220c Blades
To support network connections for specific signals, install an
interconnect module in the bay corresponding to the embedded NIC
or mezzanine signals.
Connection
Port
number
Connects to
interconnect
bay/port
Comments
NIC
NIC 1
1/Port N+8
One or two
NIC 2
2/Port N+8
single-wide
NIC 3
NIC 4
1/Port N
2/Port N
Ethernet
interconnect
modules
Mezzanine
1x/2x port 1
3/Port N
One or two
slot 1—1x or
1x/2x port 2
4/Port N
single-wide
2x cards
1x/2x port 3
1x/2x port 4
3/Port N+8
4/Port N+8
interconnect
modules
Mezzanine
slot 1—4x
cards
4x port 1 3/Port N
• One
double-wide
interconnect
module
• Only port 1 of
a two-port
card can be
connected
Mezzanine
1x/2x port 1
5/Port N
Up to four
slot 2—1x or
1x/2x port 2
6/Port N
single-wide
2x cards
1x/2x port 3
1x/2x port 4
7/Port N
8/Port N
interconnect
modules
Mezzanine
slot 2—4x
cards
4x port 1
4x port 2
5/Port N
7/Port N
One or two
double-wide
interconnect
modules
Mezzanine
1x/2x port 1
7/Port N+8
Up to four
slot 3—1x or
1x/2x port 2
8/Port N+8
single-wide
2x cards
1x/2x port 3
1x/2x port 4
5/Port N+8
6/Port N+8
interconnect
modules
Mezzanine
slot 3—4x
cards
4x port 1
4x port 2
5/Port N+8
7/Port N+8
One or two
double-wide
interconnect
modules

HPE BladeSystem c7000 Specifications

General

Form Factor	10U
Interconnect Bays	8
Blade Slots	16 half-height or 8 full-height
Device Bays	16 half-height blade server bays or 8 full-height blade server bays
Power Supplies	Up to 6 hot-plug power supplies
Cooling Fans	10 hot-plug fans
Management	Onboard Administrator
Height	17.5 inches
Width	17.6 inches
Compatibility	HPE ProLiant and Integrity server blades
Non-operating Temperature	-40° to 70°C (-40° to 158°F)
Operating Humidity	10% to 90% (non-condensing)
Non-operating Humidity	5% to 95% (non-condensing)
Networking	Dependent on installed interconnect modules
Operating Temperature	10° to 35°C (50° to 95°F)
