hpmont HD09-2S1P5G User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 6 Operation
HD09 Series User Manual V1.1 -25-
6.2 Shutdown and Operating Status Parameters
HD09 Inverter in the state of stop / run, press the key to cycle display the stop / run status
parameter.
• Stop status parameter: F18.08 Set frequency, DC bus voltage, AI input voltage, potentiometer input
voltage, input terminal status, output terminal status.
• Operating status parameter: F18.02 Given frequency (after acceleration and deceleration), set
frequency, output frequency, output voltage, output current, DC bus voltage.
6.3 Keypad Control Operation
In operation under keypad control (F00.11 = 0), the inverter can be started and operated directly with
keypad.
Steps are as follows:
1. Turn on the input power.
2. Set the motor parameters according to the motor nameplate: F08.00 (rated power), F08.01 (rated
voltage), F08.02 (rated current), F08.03 (rated frequency), F08.04 (rated speed).
3. Set the operating frequency: F00.13, range 0.0 - 50.0Hz.
4. Set acceleration / deceleration time: F03.01 (acceleration time), F03.02 (deceleration time).
5. Press Key (standard) / key (optional), the inverter starts.
6. Press key (standard) / key (optional), the inverter stops.
