Chapter 7 Detailed Function Introduction Shenzhen Hpmont Technology Co., Ltd.
-52- HD09 Series User Manual V1.1
7.15 F20: Fault Protection Parameter
Overload protection (F20.00)
Ref. Code Function Description Setting Range [Default]
F20.00 Overload protection 00000 - 10000 [00000]
00000: Enable. 10000: Shielding.
F20.01 Overload pre-alarm detection threshold 20.0 - 200.0 [150.0%]
Defines the current threshold for overload pre-alarm protection. The setting range is a percentage value of
the motor’s or the inverter’s rated current.
F20.02 Overload pre-alarm detection time 0.0－60.0 [5.0s]
When the inverter output current is greater than the overload pre-alarm detection level (F20.01) and the
duration is greater than the overload pre-alarm detection time (F20.02), the inverter reports E0017 fault
(inverter overload) or E0019 fault (motor overload).
O
utput phase fault (F20.10, F20.11)
Ref. Code Function Description Setting Range [Default]
F20.10 Detecting datum for output phase fault 0 - 50 [20%]
F20.11
Detecting time for output phase fault
0.00 - 20.00 [3.00s]
F20.10 is percentage compared to rated current.
when the inverter output detects current has not reached a certain phase detecting datum (F20.10), and
duration is greater than the testing time (F20.11), frequency converter will give E0016 (output phase fault).
• F20.10 = 0 or F20.11 = 0, converter do not detect output phase fault.
Fault self
-recovery function and fault relay action (F20.18, F20.19)
The function can recovery fault occurred in running and which is set in times (F20.18) and interval
(F20.19) automatically. In
interval, output is locked and after finishing recovering, if running command
is valid, automatic running will start.
No recovery function in below fault:
E0008: Power module failure E0021: Control board EEPROM reading and writing fault
E0013: Electricity buffer relay not suck E0024: External fault
E0014: The current detection circuit fault
Ref. Code Function Description Setting Range [Default]
F20.18
Automatic reset number
0 - 100 [0]
When set to 0, it means that automatic reset is disabled and fault protection is performed immediately.
• The fault auto reset count is automatically cleared when no fault is detected within 5 minutes.
• When an external fault is reset, the fault auto reset count is cleared.
F20.19
Automatic reset interval
2.0 - 20.0 [5.0s/times]
