Chapter 9 MODBUS Communication Protocol Shenzhen Hpmont Technology Co., Ltd.
-66- HD09 Series User Manual V1.1
9.4.2 Control Parameters (0x32) Address Mapping
Inverter control parameters to complete the inverter start, stop, set the operating frequency and other
functions, by retrieving the inverter status parameters to obtain the inverter running frequency, output
current and other parameters.
The control group number (0x32) is mapped to the high byte of the register address, and the index in
the group is as follows:
Register address Parameter Saving or not when power off
0x3200 Control commnad No
0x3201 Running frequency setting No
0x3204 Analogue terminals control setting No
Control commnad (0x3200) byte definition
Register contents can be defined as control commands, see table below.
Register content Control command Register address Parameter name
0x1001 Forward command 0x1020 External fault shutdown
0x1003 Reverse command 0x1040 Jog forward
0x1004 Deceleration downtime 0x1080 Jog reverse
0x1010 Free stop 0x1100 Fault reset
Virtual terminal control setting (0x3204) word bit definition
Control word Value and meaning
Bit1 1: DO is valid 0:DO is invalid
Bit2 1: RLY i s val i d 0:RLY is valid
