Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
-78- HD09 Series User Manual V1.1
Ref. Code
Function
Setting Range
Default
Unit
Attribute
Setting
F15.27 FAR range 0.0 - 100.0Hz 2.5Hz 0.1Hz
F15.31 FDT level 0.0 - F00.06 50.0Hz 0.1Hz
F15.32 FDT lag - F00.06 - F00.06 1.0Hz 0.1Hz
F15.36 Preset operating time
0 - 65535h
0: Preset operating time is disabled
0h 1h
F15.37
Preset counting value
arriving
F15.38 - 9999 0 1
F15.38
Specified counting value
arriving
0 - F15.37 0 1
F15.43 Terminal output delay 0.0 - 100.0s 0.0s 0.1s
×
F16: Analogue Input / Output Terminal Parameter
F16.00
Keypad with
potentiometer function
0: Unused
2: Frequency setting source
3: Auxiliary frequency reference
5: Process PID feedback
0 1
×
F16.01 AI function 2 1
×
F16.05 AI bias -100.0 - 100.0% 0.0% 0.1%
F16.06 AI gain 0.00 - 10.00 1.00 0.01
F16.07 AI input filtering time 0.01 - 10.00s 0.05s 0.01s
F16.17
DI4 max. input pulse
frequency
0.0 - 50.0kHz 10.0kHz
0.1kH
z
F16.18
DI4 input pulse filtering
time
0 - 500ms 10ms 1ms
F16.19 AO function
0: Unused
2: Reference frquency (0 - max. output
frequency)
3: Motor speed (0 - max. output
frequency corresponding to speed)
5: Output current (0 - twice motors
rated current)
11: Output voltage (0 - 1.2 times
inverters rated voltage)
12: Bus voltage (0 - 2.2 times inverters
rated voltage)
2 1
F16.21 DO function 0 1
F16.22 AO bias -100.0 - 100.0% 0.0% 0.1%
F16.23 AO gain 0.0 - 200.0% 100.0% 0.1%
F16.26
DO max. output pulse
frequency
0.1 - 50.0kHz 10.0kHz
0.1kH
z
