Shenzhen Hpmont Technology Co., Ltd. Chapter 9 MODBUS Communication Protocol
HD09 Series User Manual V1.1 -67-
9.4.3 Status Parameter (0x33) Address Mapping
The group number (0x33) of the status parameter is mapped to the high byte of Register address. The
index of the group is shown in the following table:
Address Parameter Address Parameter
0x3300 Inverter series 0x331A Keypad potentiometer input voltageM
0x3301 U1 board software version 0x331B AI input voltage
0x3302 I1 board software version 0x331C AI input voltage (after processing)
0x3303 U1 board software non-standard version 0x3323 DI4 terminal pulse input frequency
0x3304 I1 board software non-standard version 0x3324 AO output
0x3305 Operation panel software version 0x3326 High speed output pulse frequency
0x3306 Customized serial number 0x3327 Radiator temperature
0x3308 Inverter rated current 0x332C Process PID given
0x330A Inverter rated current 0x332D Process PID feedback
0x330B Main reference frequency channel 0x332E Process PID error
0x330C Main set frequency 0x332F Process PID integral term
0x330D Auxiliary set frequency 0x3330 Process PID output
0x330E Set frequency 0x3331 External count value
0x330F Given frequency (after Acc. / Dec.) 0x3332 Input terminal status
0x3310 Output frequency 0x3333 Output terminal status
0x3311 Set Rpm 0x3334 MODBUS communicaiton status
0x3312 Running Rpm 0x3337 Power-on time accumulated (hours)
0x3314 The output voltage 0x3338 Run time accumulated (hours)
0x3315 Output current 0x333D Current fault
0x3319 DC bus voltage
9.5 Special Instructions
1. The host machine can read but cannot change the inverter parameters: F08 group (asynchronous
motor), F17 group (SCI communication), keep the parameters.
2. The host machine communication cannot change F01.00 (user password), but you can write F01.00
verify the user password, the host machine gets the function parameters of the inverter, after the
change, by writing invalid the password to F01.00 and make the host machine no permission to
change the function parameters of the inverter.
3. Various multi-function input terminal function settings will lead to the same function, through the
MODBUS protocol to modify the multi-function terminal function to avoid this situation.
