Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
-74- HD09 Series User Manual V1.1
Ref. Code
Function
Setting Range
Default
Unit
Attribute
Setting
F04.03 Setting digital reference 0.0 - 100.0% 0.0% 0.1%
F04.04 Proportional gain (P) 0.00 - 10.00 2.00 0.01
F04.05 Integral time (I) 0.01 - 10.00s 1.00s 0.01s
F04.06 Integral upper limit 0.0 - F00.08 50.0Hz 0.1Hz
F04.07 Differential time (D) 0.00 - 10.00s 0.00s 0.01s
F04.08
Differential amplitude limit
value
0.0 - F00.08 20.0Hz 0.1Hz
F04.09 Sampling cycle (T ) 0.01 - 50.00s 0.10s 0.01s
F04.10 Bias limit 0.0 - 20.0% 2.0% 0.1%
F04.13
PID regulator upper limit
value
0.0 - F00.08 50.0Hz 0.1Hz
×
F04.14
PID regulator lower limit
value
0.0 - F00.08 0.0Hz 0.1Hz
×
F04.15 PID regulator characteristic
0: Positive characteristic
1: Negative characteristic
0 1
×
F04.16
Integral regulation
selection
0: Stop integral regulation when the
frequency reaches the upper or lower
limit
1: Continue the integral regulation
when the frequency reaches the
upperor lower limit
0 1
×
F04.17 PID output filter time 0.01 - 10.00s 0.05s 0.01s
F04.18
PID output reverse
selection
0: PID regulation disable reverse (when
PID output is negative, 0 is the limit)
1: PID regulation enable reverse
0 1
×
F04.19
PID output reverse
frequency’s upper limit
0.0 - F00.08 50.0Hz 0.1Hz
×
F05: External Given Curve Parameters
F05.01 Minimum reference of line 0.0% - F05.03 0.0% 0.1%
F05.02
Minimum reference
corresponding value of line
0.0 - 100.0% 0.0% 0.1%
F05.03 Maximum reference of line F05.01 - 100.0% 100.0% 0.1%
F05.04
Maximum reference
corresponding value of line
0.0 - 100.0% 100.0% 0.1%
F05.17 Skip frequency F00.09 - F00.08 0.0Hz 0.1Hz
×
F05.20 Range of skip frequency 0.0 - 30.0Hz 0.0Hz 0.1Hz
×
F06: Multistage Speed Function
