hpmont HD09 Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09 Series User Manual V1.1 -75-
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F06.00
Multi-step frequency
Command 1
F00.09 - F00.08 5.0Hz 0.1Hz
○
F06.01
Multi-step frequency
Command 2
F00.09 - F00.08 5.0Hz 0.1Hz
○
F06.02
Multi-step frequency
Command 3
F00.09 - F00.08 5.0Hz 0.1Hz
○
F06.03
Multi-step frequency
Command 4
F00.09 - F00.08 5.0Hz 0.1Hz
○
F06.04
Multi-step frequency
Command 5
F00.09 - F00.08 5.0Hz 0.1Hz
○
F06.05
Multi-step frequency
Command 6
F00.09 - F00.08 5.0Hz 0.1Hz
○
F06.06
Multi-step frequency
Command 7
F00.09 - F00.08 5.0Hz 0.1Hz
○
F08: Motor Parameter
F08.00 Rated power of motor 0.2 - 5.5kW
Dependent
on HD09
0.1kW
×
F08.01 Rated voltage of motor 0V - inverter’s rated voltage 1V
×
F08.02 Rated current of motor 0.01 - 99.99A 0.01A
×
F08.03 Rated frequency of motor 1 - 1000Hz 50Hz 1Hz
×
F08.04 Rated Rpm of motor 1 - 24000rpm
Dependent
on HD09
1rpm
×
F08.06
Parameter auto-tuning of
motor
0: Auto-tuning is disabled
1: Stationary auto-tuning
0 1
×
F08.07 Stator resistance of motor 0.00 - 99.99Ω
Dependent
on HD09
0.01Ω
×
F09: V/f Controlling Parameter
F09.01 V/f frequency value F3 F09.03 - 100.0% (F08.03) 100.0% 0.1%
×
F09.02 V/fvoltage valueV3 F09.04 - 100.0% (F08.01) 100.0% 0.1%
×
F09.03 V/f frequency value F2 F09.05 - F09.01 (F08.03) 0.0% 0.1%
×
F09.04 V/f voltage value V2 F09.06 - F09.02 (F08.01) 0.0% 0.1%
×
F09.05 V/f frequency value F1 0.0% - F09.03 (F08.03) 0.0% 0.1%
×
F09.06 V/f voltage value V1 0.0% - F09.04 (F08.01) 0.0% 0.1%
×
F09.07 Torque boost 0.0 - 30.0% 2.0% 0.1%
×
F09.08
Cut-off point used
formanual torque boost
0.0 - 50.0% (F08.03) 30.0% 0.1%
○
F09.09
Motor transfer
compensation gain
0.0 - 300.0% 0.0% 0.1%
○
