Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
-76- HD09 Series User Manual V1.1
Ref. Code
Function
Setting Range
Default
Unit
Attribute
Setting
F09.10
Compensation filtering
time for motor transfer
0.01 - 10.00s 0.10s 0.01s
F09.11
Differential compensation
for motor differential
0.0 - 250.0% 200.0% 0.1%
×
F09.12
The time constant of the
motor compensation
0.1 - 25.0s 2.0s 0.1s
F09.14
AVR (automatic voltage
regulation) function
0: No action
1: Keep acting
2: No action only in Dec.
1 1
F09.15
Oscillation-suppression
mode
0: Oscillation-suppression mode 1
1: Oscillation-suppression mode 2
0 1
F09.16
Oscillation-suppression
coefficient
0 - 200 50 1
F15: Digital Input / Output Terminals Parameter
F15.00 DI1 function
0: Unused
1: Inverter enabled
2,3: FWD / REV function
4: Three-wire operation mode
8: AI to be the frequency source
11: Terminal control mode to be the run
command source
13 - 15: Multi-step frequency terminal
1 - 3
17: Frequency ramp (UP)
18: Frequency ramp (DN)
19: Clearing auxiliary frequency setting
20,21: Forward and reverse jog
command control input (JOGF / JOGR)
26,27: Selection terminals in Ace. and
Dec. time 1, 2
41: Coast to stop (normally-open input)
42: Coast to stop (normally-closed
input)
44: External fault signal (normally-open
input)
2 1
×
F15.01 DI2 function 3 1
×
F15.02 DI3 function 0 1
×
