hpmont HD09 Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 10 Parameter
HD09 Series User Manual V1.1 -77-
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F15.03 DI4 function
45: External fault signal (normally-
closed input)
46: External resetinput (RST)
50: Clearing the counter to zero
51: Counter’s triggering signal input
53: Pulse frequency input (only DI4
terminal is enabled)
ADI is valid when F15.44 is not as 0. As 0,
only AI is valid.
0 1
×
F15.44
AI terminal (ADI function)
selection
0 1
×
F15.12
Acc. / Dec. rate of UP / DN
terminal
0.0 - 99.9Hz/s 1.0Hz/s
0.1
Hz/s
×
F15.14
Terminal detecting filter
number
0 - 10000 2 1
○
F15.15
Terminal input positive and
negative logic setting
Bit0 - Bit3 is corresponding to DI1 - DI4
Bit12 is corresponding toAI
Bitx: DIy terminal input positive and
negative logic
0: Positive logic
1: Negative logic
0 1
○
F15.16 FWD / REV operation mode
0: Two-wire operation mode1
1: Two-wire operation mode2
2: Three-wire operation mode 1
3: Three-wire operation mode 2
0 1
×
F15.19 DO function
0: Unused
2: Inverter is running (RUN)
3: Inverter is forward running
4: Inverter is reverse running
5: Inverter is DC braking
9: Frequency detection threshold (FDT)
11: Frequency arriving signal (FAR)
20: Output data from SCI
communication
21: Preset operating time out
23: Preset counting value reach
24: Indicating counting value reach
30: Overload signal (OL)
31: Inverter fault
38: High-frequency output (only DO)
2 1
×
F15.20 Relay function 31 1
×
