HPRT TP80C User Manual

TP80C User Manual
23
5.3 Power Supply Interface
Figure 5.3
PIN
SIGNAL NAME
1
+24V
2
GND
3
N.C
SHELL
F.G
Notes ：

Strictly prohibit unplug the cable while the printer is power on.
 When arranging the line of communication, you have to avoid paralleling with the strong
current.

you have to use the shielded communication line.
