HSM FA 400.2 - Maintenance and Care

HSM FA 400.2 Shredder
12 2004-12
9. Maintenance and care
Cleaning the cutting block (once daily)
• Switch off the shredder.
• Squirt special cutting block oil through the paper feed opening onto the blade rollers.
Order no. 1.235.997.401 for a 250 ml bottle
Order no. 1.235.997.500 for 5 litre container
• Let the cutting block run forwards and backwards several times without feeding in any paper.
➪ This loosens paper dust and particles.
Checking the chain tension (twice yearly)
• Switch off the shredder.
• Pull out the power plug.
• Remove the tray and the left cover panel.
The sag of the chain should be 4 – 10 mm.
If you need to tighten the chain:
• Remove the right cover panel.
• Loosen the nuts and push the motor and the tensioning screws until the
chain sags by 4 – 10 mm.
•Tighten the nuts again.
• Put the cover panels and the tray back on.
Note:
Do not tighten the chain too much, as this will cause premature wear on the chain and bearings.
