Gx Series
EN - 86
3. If the HT53L probe is used, select the color of the
LED source under test from the options: STD
(standard white light source), White, Red, Yellow,
Green, Blue and Purple as shown in the screen to the
side
Confirm the choices by going back to the initial
measurement screen
4. Insert in the auxiliary In1 input the transducer necessary for the desired measurement as
shown in Fig. 33
5. The measured value appears on the display in real time
as shown in the screen to the side.
Press the SAVE button or touch the icon to save
the measurement (see § 7.1).
