HT HT65 User Manual

HT65
EN - 15
5.8. TEMPERATURE MEASUREMENT WITH K-TYPE PROBE
CAUTION
Before attempting any temperature measurement, cut off power supply from
the circuit to be measured and make sure that all capacitors are discharged,
if present.
Fig. 9: Use of the instrument for Temperature measurement
1. Select position °C or position °F
2. Insert the provided adapter into input terminals
Hz%V
:
(polarity +) and COM
(polarity -) (see Fig. 9)
3. Connect the provided K-type wire probe or the optional K-type thermocouple (see §
7.3.2) to the instrument by means of the adapter, respecting the positive and negative
polarity on it. The display shows the value of temperature
4. The message
“OL.” indicates that the value of temperature exceeds the maximum
measurable value.
5. To use the HOLD function, see § 4.2.

HT HT65 Specifications

General

Brand	HT
Model	HT65
Category	Multimeter
Language	English
