HT65
EN - 19
7. TECHNICAL SPECIFICATIONS
7.1. TECHNICAL CHARACTERISTICS
Accuracy calculated as [%reading + (num. digits*resolution)] at 18°C y 28°C <75%RH
DC Voltage
Range (*) Resolution Accuracy Input impedance
Overload
protection
400.0mV 0.1mV
r(1.2%rdg + 4dgt)
10M:
1500VDC
4.000V 0.001V
40.00V 0.01V
400.0V 0.1V
1500V 1V
r(1.5%rdg + 2dgt)
AC TRMS Voltage
Range Resolution
Accuracy (*)
(50Hz
y
1kHz)
Input impedance
Overload
protection
4.000V 0.001V
r(1.2%rdg + 10dgt)
10M:
1000VDC/ACrms
40.00V 0.01V
r(1.5%rdg + 3dgt)
400.0V 0.1V
1000V 1V
r(2.0%rdg + 4dgt)
(*) Accuracy specified from 5% to 100% of the measuring range; Frequency range: 50Hz ÷ 1kHz (sinusoidal waveform)
For not sinusoidal waveforms the accuracy is: r(10.0%rdg + 10dgt) (50Hz÷60Hz)
DC/AC TRMS Voltage with low impedance (LoZ)
Range Resolution Accuracy (*) Input impedance Overload protection
4.000V 0.001V
r(3.0%rdg+40dgt) approx 3k:
600VDC/ACrms
40.00V 0.01V
400.0V 0.1V
600V 1V
(*) Accuracy specified from 5% to 100% of the measuring range; Frequency range: 50Hz ÷ 1kHz (sinusoidal waveform)
For not sinusoidal waveforms the accuracy is: r(10.0%rdg + 10dgt) (50Hz÷60Hz)
Diode test
Function Resolution
Accuracy
Max voltage with
open circuit
Overload protection
1mV
r(10%rdg+5dgt)
<3VDC 250VDC/ACrms
DC Current with transducer clamp
Range Output ratio Resolution Accuracy (*) Overload protection
10A 100mV/1A
0.01A
r(1.5%rdg + 6dgt)
1000VDC/ACrms
40A (**)
10mV/1A
r(1.5%rdg + 26dgt) (***)
100A
0.1A
r(1.5%rdg + 6dgt)
400A (**)
1mV/1A
r(1.5%rdg + 26dgt) (***)
1000A 1A
r(1.5%rdg + 6dgt)
(*) Accuracy referred to only instrument without transducer clamp; (**) With HT4006 transducer; (***) Accuracy instrument + clamp
