HTC 80 iD Usage
1.1 17
The lowered operating positions for the pre-separator are use for handling a full
Longopac on the collection plate (pos 5 Figure3-1, page8), stool or similar resting
place.
Figure 4-3. Locking pin for the pre-separator
Figure 4-4. Transport position
