HTC 80 iD - Control Cabinet; Resetting the Motor Protection

Service HTC 80 iD
42 1.1
6.5 Control cabinet
Figure 6-4. Control cabinet
Note!
The dust extractor must not be connected to the mains supply when carrying
out the points below.
6.5.1 Resetting the motor protection
1. Cut the power to the dust extractor by pulling the plug out of the electrical
socket, see Figure3-3, page10.
2. Open the electrical cabinet.
3. Press the motor protection Reset button, see Figure6-4, page42.
4. Close the electrical cabinet.
5. Connect the dust extractor to the mains supply by plugging in the plug.
6. Try to start the dust extractor by pressing the "I" button on the dust extractor's
keypad.
