REMOVE THE RECEIVER FROM THE
HOUSING CAREFULLY
DISASSEMBLY COMPLETED!
NOTE: DUE TO THE S/N LABEL
HINDS THE BACKWARD OF BEZEL
AND YOU CAN’T SEE THE SERIAL
NUMBER. IT’S NO NEED TO FILL IN
THE SERAIL NUMBER WHEN
REPLACING THE DEFECTIVE
T/P+LCD MODULE
