RIP THE TAPE OF POWER AND
VOLUME SWITCH THEN STICK ON THE
FRAME OF THE HOUSING
PUSH THE BT/WIFI COAXIAL CABLE
INTO THE FILLISTER OF THE FRONT
BEZEL
INSERT THE WIFI/BT COAXIAL CABLE
INTO THE CONNECTOR OF NAVI
BOARD
