Doc. Title
Diamond Service Manual
Page 58 of 109
HTC CONFIDENTIAL
SM-TP001-0704
HTC Corporation
WinCE Test
Bluetooth Test - 1
1. Tap icon Comm Manager on the
Today screen and turn on Bluetooth.
2. Tap the icon “Settings” down-right
the corner of the screen and select
the “Make this device….” Checkbox.
3. Press Action key (Jog-ball) to go
next test pattern.
Bluetooth Test-2
4. Tap Start->Settings->Connections->
Beam and select “Receive all….”
Checkbox.
5. To create a file, tap Start->Programs
->Notes->New
6. Tap and select the “Beam file…”
Bluetooth Test-3
7. Once device is searched, tap the
device to send the file.
8. Return to Today screen and tap
S
tart->Program->Comm Manager
->Bluetooth to turn off Bluetooth.
To Next Page
