Display Test (and RED/ GREEN pattern)
13. Press Action key to select Display
Test
on Function test menu.
14.
A
fter the test pattern is show up,
please check the pattern if any
un-uniform color or chromatist.
15. Press Action key to continue the
next test p
attern.
Display Test (BLUE/ BLACK pattern)
16. Press Action key to continue the
next test pattern.
Display Test (WHITE/Color bar pattern)
17. Press Action key to continue the
next test pattern.
