HUANUO HNCM2 - Step 3: Attach VESA Plate; For Laptop; For Monitor with Flat Back; For Monitor with Curved or Recessed Back

5
Step 3
Attach the VESA Plate to the Laptop Tray or Monitor
Step 4
Slide the Monitor onto the Head of Swivel Arm
h
s
r
t
u
v
q
For Laptop For Monitor with Flat Back
For Monitor with Curved
or Recessed Back
Slide the monitor onto the head of Swivel
Arm(d) as shown in the above diagram.
Install the security Nut(h). Make sure the
security nut is installed before you rotate the
monitor.
