Huawei Ascend - Page 19

Y210 Mobile Phone
Maintenance Manual
7 Disassembly Procedure
Issue 1.0 (2012-11-28)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
10. Release the volume key FPC.
9. Remove the volume key.
8. Use a cover opener to release the latches between
the rear cover and the front cover.
7. Use the disassembly tab to release the latch in the
upper left corner.
6. Use the disassembly tab to release the latch in the
upper left corner.
5. Remove the eight screws from the rear cover.
