− PSU plus RRU

Easy to operate
− Can be installed by one person
− Same set of mounting kits for all scenarios, survey-free
− Quick connectors for input and output ports and communications ports, which are
foolproof and prevents reverse connection
− Plug-and-use, no need to set parameters or communications addresses

Easy to expand
− PSU: online expansion to increase loading capacity
− Lithium battery: online expansion to increase backup time

Easy to maintain
− Remote monitoring
2.3 System Configuration
Table 2-1 Typical system capacity specifications (DPU40D-N06A3)
Number of
Load Routes
Number of
PSUs (PCS)
Number of
Lithium
Batteries
(PCS)
Power
Backup
Capacity (Wh)
(DBU20B)
Power
Backup
Capacity (Wh)
(DBU50B)
3
1
0
0
0
6
2
0
0
0
3
1
1
960
2400
3
1
2
1920
4800
3
1
3
2880
7200
6
2
1
960
2400
6
2
2
1920
4800
6
2
3
2880
7200
12
4
4
3840
9600

PSU (DPU40D-N06A3):
− When one PSU is configured, the maximum output power of the PSU is 2000 W.
− When two PSUs are configured, the maximum output power of the PSUs is 3800
W.
− When three or four PSUs are configured, the maximum output power of the PSUs is
2000 W x number of PSUs x 0.8.

Lithium battery (DBU20B-N12A3):
