Chapter 4 Technical Specifications
General Specifications
Item Feature
ADSL Standards:
ANSI T1.413 Issue 2
ITU G.992.1 (G.dmt) Annex A
ITU G.992.2 (G.lite) Annex A
ITU G 994 1 (G.hs)
ADSL2 Standards:
ITU G.992.3 (G.dmt.bis) Annex A
ADSL Standards
ADSL2+ Standards:
ITU G.992.5 Annex A
ADSL Data Rate
Downstream: up to 24 Mbit/s
Upstream: up to 1 Mbit/s
One ADSL port
RJ-11, inner pair (pin 2, 3)
Performance
Pass DSL Forum TR-048/TR-067
Performance Criteria
Four Fast Ethernet
ports
RJ-45, 10/100 Mbit/s, MDI/MDIX
Auto-sensing
Standard Compliance
IEEE 802.3, IEEE 802.3u
One USB port
Type B connector (for HG520 only)
Standard Compliance
USB Implementation Forum USB 1.1
Specification
