22
7.3 Default Settings
Parameter Setting
IP address of the LAN port 192.168.1.1
Subnet mask of the LAN port 255.255.255.0
User name used to log in to
the web-based configuration utility
user
Password used to log in to
the web-based configuration utility
user
SSID used to access wireless
network
Check the label on the HG532t's rear
panel
WLAN key used to access wireless
network
Check the label on the HG532t's rear
panel
DHCP server function Enable
WLAN function Enable
WPS function Enable
7.4 Technical Specifications
Item Specification
Ambient temperature for operation Adaptable temperature:
0°C to 50°C (32°F to 122°F)
Recommendable temperature:
0°C to 40°C (32°F to 104°F)
Dimensions (with antenna,
L × W × H)
About 203 mm × 35.5 mm × 119 mm
Weight
(Not including the power adapter)
< 360 g
Relative humidity for operation 5% to 95%, non-condensing
