3.12 Reserved Interface
The ME909 module provides 24 reserved pins. All reserved pins cannot be used by
the customer. All of them must be leave unconnected.
Table 3-14 Reserved pin
Pin No.
Pin Name
I/O
Description
9, 10, 16–20, 27, 35, 43–46, 60–69, 92
Reserved
-
Reserved
3.13 NC Interface
The ME909 module has 23 NC pins. All NC pins should not be connected. Please
keep these pins open.
Table 3-15 NC pin
Pin No.
Pin Name
I/O
Description
25, 26, 31, 33, 37–41, 82–84,
94–99, 103, 117–120
NC
-
Not connected, please
keep open.
3.14 Tunable Antenna Control
The module provides 4 tunable antenna control pins. This function is under
development.
Table 3-16 List of tunable antenna control pins
Pin No.
Pin Name
I/O
Description
DC Characteristics(V)
Min.
Typ.
Max.
21
ANT_TUNE0
O
Tunable antenna
control signal bit 0
–0.3
1.8
2.1
22
ANT_TUNE1
O
Tunable antenna
control signal bit 1
–0.3
1.8
2.1
23
ANT_TUNE2
O
Tunable antenna
control signal bit 2
–0.3
1.8
2.1
24
ANT_TUNE3
O
Tunable antenna
control signal bit 3
–0.3
1.8
2.1
The mapping of each band to ANT_TUNE outputs is configurable.
