HUAWEI ME909 Series LTE LGA Module
Hardware Guide
RF Specifications
Issue V0.3 (2013-05-21)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
42
Table 4-2 ME909u-521 conducted Rx sensitivity (Unit: dBm)
Item
3GPP
Protocol
Claim (dBm)
ME909u-521 Test Value (dBm)
Min.
Typ.
Max.
GSM850
GMSK
(BER<2.43%)
< –102
-
TBD
TBD
8PSK (MCS5,
BLER<10%)
< –98
-
TBD
TBD
GSM900
GMSK
(BER<2.43%)
< –102
-
TBD
TBD
8PSK (MCS5,
BLER<10%)
< –98
-
TBD
TBD
GSM1800
GMSK
(BER<2.43%)
< –102
-
TBD
TBD
8PSK (MCS5,
BLER<10%)
< –98
-
TBD
TBD
GSM1900
GMSK
(BER<2.43%)
< –102
-
TBD
TBD
8PSK (MCS5,
BLER<10%)
< –98
-
TBD
TBD
UMTS Band I (BER<0.1%)
< –106.7
-
TBD
TBD
UMTS Band II (BER<0.1%)
< –104.7
-
TBD
TBD
UMTS Band V (BER<0.1%)
< –106.7
-
TBD
TBD
UMTS Band VIII (BER<0.1%)
< –103.7
-
TBD
TBD
LTE Band I (FDD QPSK
throughput>95%)
< –96.3 (10
MHz)
-
TBD
TBD
LTE Band II (FDD QPSK
throughput>95%)
< –94.3 (10
MHz)
-
TBD
TBD
LTE Band III (FDD QPSK
throughput>95%)
< –93.3 (10
MHz)
-
TBD
TBD
LTE Band V (FDD QPSK
throughput>95%)
< –94.3 (10
MHz)
-
TBD
TBD
LTE Band VII (FDD QPSK
throughput>95%)
< –94.3 (10
MHz)
-
TBD
TBD
LTE Band VIII (FDD QPSK
throughput>95%)
< –93.3 (10
MHz)
-
TBD
TBD
LTE Band XX (FDD QPSK
throughput>95%)
< –93.3 (10
MHz)
-
TBD
TBD
