3 Description of the Application Interfaces
3.1 About This Chapter
This chapter mainly describes the external application interfaces of the MU609
module, including:

LGA Interface

Power Interface

Signal Control Interface

UART Interface

USB Interface

USIM Card Interface

General Purpose I/O Interface

JTAG Interface

RF Antenna Interface

Reserved Interface

NC Interface
3.2 LGA Interface
The MU609 module uses a 145-pin LGA as its external interface. For details about the
module and dimensions, see "Dimensions and Interfaces".
