3.6 USIM Card Interface
3.6.1 Overview
The MU736 module provides a USIM card interface complying with the ISO 7816-3
standard and supports both 1.8 V and 3.0 V USIM cards.
Table 3-10 USIM card interface signals
Pin
No.
Pin Name
I/O
Description
DC Characteristics (V)
Min.
Typ.
Max.
30
UIM_RESET
O
USIM Reset
–0.3
1.8/2.85
1.98/3.0
32
UIM_CLK
O
USIM clock
–0.3
1.8/2.85
1.98/3.0
34
UIM_DATA
IO
USIM DATA
–0.3
1.8/2.85
1.98/3.0
36
UIM_PWR
PO
USIM POWER
–0.3
1.8/2.85
1.98/3.0
3.6.2 Circuit Recommended for the USIM Card Interface
As the MU736 module is not equipped with an USIM socket, you need to place an
USIM socket on the user interface board.
Figure 3-25 shows the circuit of the USIM card interface.
