HUAWEI MU736 HSPA+ M.2 Module
Hardware Guide
Overall Description
Issue 05 (2014-01-14)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
2 Overall Description
2.1 About This Chapter
This chapter gives a general description of the MU736 module and provides:

Function Overview

Circuit Block Diagram
2.2 Function Overview
Table 2-1 Features
Feature
Description
Physical
Features

Dimensions (L × W × H): 42 mm × 30 mm × 2.3 mm

Weight: about 6 g
Operating
Bands
WCDMA/HSDPA/HSUPA/HSPA+: 850 MHz/900 MHz/1700 MHz
(AWS)/1900 MHz/2100 MHz
GPRS/EDGE: 850 MHz/900 MHz/1800 MHz/1900 MHz
GPS: L1
Operating
Temperature
Normal operating temperature: –10°C to +55°C
Extended operating temperature
[1]
: –20°C to +70°C
Storage
Temperature
–40°C to +85°C
Moisture
RH5% to RH95%
Power
Voltage
3.135 V to 4.4 V (3.3 V is typical)
AT
Commands
See the HUAWEI MU736 HSPA+ M.2 Module AT Command
Interface Specification
Application
USIM (3.0 V or 1.8 V)
