(Optional) Connecting the Low-Temperature Component Cables

7.6

The figure shows the cable

routing of NetCol8000-A045.

Also connect L/N to another

outdoor unit if NetCol8000-

A090 or NetCol8000-A120 is

configured.

(1) Low-temperature

component

Low-temperature component

power cable to outdoor unit

Low-temperature component

power cable from outdoor

unit to indoor unit

NetCol8000-A060 Upflow

NetCol8000-A060/A120 Downflow
