7
Installation Scenario
4.1
Unit: mm
Horizontal Installation
NetCol500-A060
NetCol500-A110
Unit: mm
Vertical Installation
Compact Installation
Unit: mm
NetCol500-A060
NetCol500-A110
Make sure that no shelter
is above the outdoor unit.
NetCol500-A80
