Engineering Materials
Mandator
y items
Refrigera
nt pipe
0 m < L ≤ 60 m:
Gas pipe:
outer diameter of 7/8 inch (22.22 mm) ; wall thickness of 1.2
mm; operating pressure > 4.5 MPa
Liquid
pipe:
outer diameter of 5/8 inch (15.88 mm) ; wall thickness of 1.0
mm; operating pressure > 4.5 MPa
60 m < L ≤ 100 m
:
Gas pipe:
outer diameter of 1 inch (25.4 mm) ; wall thickness of
1.2 mm;
operating pressure > 4.5 MPa
Liquid
pipe: outer diameter of 3/4 inch (19.05 mm) ; wall thickness of
1.0
mm; operating pressure > 4.5 MPa
Thermal insulation foam
, thickness ≥ 9.2mm
Oil traps and inverted traps , Pipe supports
Mandator
y items
(Optional)
Humidifie
r water
inlet pipe
•
Connecting rigid pipe (for engineering): G 3/4-
inch inner screw thread
to rigid pipe connector, rigid pipe (made of PP-R or other materials)
•
Connecting hose (for engineering): G 3/4-inch inner screw thread to
pagoda connector, hose (made of EPDM or other materials)
Drainpipe
•
Connecting rigid pipe (for engineering): G 3/4-
inch outer screw thread
to rigid pipe connector, rigid pipe (made of PP-R or other materials)
•
Connecting hose (for engineering): G 3/4-inch outer screw thread to
pagoda connector, hose (made of EPDM or other materials)
•
Thermal insulation foam
Cables
•
Power cable of NetCol8000-A045 indoor unit: 5 x 10 mm²
(L1/L2/L3/N/PE)
•
Power cable of NetCol8000-A055 indoor unit: 5 x 10 mm²
(L1/L2/L3/N/PE)
•
Power cable of NetCol8000-A060 indoor unit: 5 x 10 mm²
(L1/L2/L3/N/PE)
•
Power cable of NetCol8000-A090 indoor unit: 4 x 25 mm²
(L1/L2/L3/N) + 16 mm² (PE)
•
Power cable of NetCol8000-A120 indoor unit: 4 x 25 mm²
(L1/L2/L3/N) + 16 mm² (PE)
•
Power cable of outdoor unit: 4 x 2.5 mm² (L1/L2/L3/PE)
•
Signal cable of outdoor unit and indoor unit: 3 x 1.5 mm² (This cable
is required only for the outdoor unit configured with a temperature
control intelligent monitoring board, that is, the 52273539 or
52273541 outdoor unit. This cable is not required for other outdoor
units.)
Base
Base
of indoor unit (recommended for downflow unit) , outdoor unit
support
or concrete base (determined based on scenarios)
When the NetCol8000-A045/A055/A060 indoor unit is used, prepare
one group of outdoor unit cables for each indoor unit (if two indoor
units are used, prepare two groups of outdoor unit cables). When
the NetCol8000-A090/120 indoor unit is used, prepare two groups of
outdoor unit cables for each indoor unit.
