Installing CRPC Plug-in Frames
Installing the CRPC plug-in frame
c
Exterior
a
Mounting holes
b
Fan
CRPC board
Power ports
a
Mounting holes to attach
mounting ears on the N63E
cabinet
a
2
2
1
1
Install the mounting ears. Attach the CRPC plug-in frame to the cabinet columns.
If an OptiX OSN 9560 shares a cabinet with an OptiX OSN 3500/7500, do not install a CRPC plug-in frame in
that cabinet.
12±1.2 Kgf.cm
M4
30±3 Kgf.cm
M6
CAUTION
