Installing Components
• Front view of the cabinet
Component Mounting Hole Remarks
OSN 9560
4, 5, 11, 17, 24,
30, 37, 38
The fan assembly
and air filter net are
installed inside the
subrack.
Before laying out cables, remove the front door and side
panels of the cabinet. For details, see the N63E Cabinet
Installation Guide. To prevent injury or equipment damage,
two people should perform this operation. One holds the
subrack and the other tightens panel screws.
4
5
11
17
24
30
37
38
42
48
50
57
59
74
75
78
82
Fiber management
tray
42
OSN 3500
48, 50, 57, 59
74, 75
78,
82
Cable
distribution plate
DC power
distribution box
The fan assembly
and air filter net are
installed inside the
subrack.
• Mounting holes for subracks
Installing Subracks
Mounting holes for the OptiX OSN 9560 and OptiX OSN 3500
a
Before installing the OSN 9560 in the cabinet, remove the fan
assembly and air filter net at the bottom of the subrack to
create some working space to complete the installation. After
the OSN 9560 has been installed, return the fan assembly and
air filter net to their places.
NOTE
