Operation Manual - STP
Quidway S3000 Series Ethernet Switches Chapter 1 RSTP Configuration
2-19
You can configure the max transmission speed on a port with either of the
above-mentioned measures. For more about the commands, refer to the Command
Manual.
This parameter only takes a relative value without units. If it is set too large, too many
packets will be transmitted during every Hello Time and too many network resourced
will be occupied. The default value is recommended.
By default, the max transmission speed on every Ethernet port of the switch is 3.
2.2.9 Configure a Port as an Edge Port
An edge port refers to the port not directly connected to any switch or indirectly
connected to a switch over the connected network.
You can configure a port as an edge port or non-edge port in the following ways.
I. Configure in system view
Perform the following configuration in system view.
Table2-12 Configure a port as an edge port or a non-edge port
Operation Command
Configure a port as an edge port. stp interface interface-list edged-port enable
Configure a port as a non-edge port. stp interface interface-list edged-port disable
Restore the default setting, non-edge port, of the
port.
undo stp interface interface-list edged-port
II. Configure in Ethernet port view
Perform the following configuration in Ethernet port view.
Table2-13 Configure a port as an edge port or a non-edge port
Operation Command
Configure a port as an edge port. stp edged-port enable
Configure a port as a non-edge port. stp edged-port disable
Restore the default setting, non-edge port, of the port. undo stp edged-port
You can configure a port as an edge port or a non-edge port with either of the
above-mentioned measures. For more about the commands, refer to the Command
Manual.
After configured as an edge port, the port can fast transit from blocking state to
forwarding state without any delay. In the case that BPDU protection has not been
