Item Description
Dimensions (H x
W x D)
● Basic dimensions (excluding the parts protruding from
the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x
17.40 in. x 16.54 in.)
● Maximum dimensions (the depth is the distance from
ports on the front panel to the handle on the rear panel):
43.6 mm x 442.0 mm x 444.2 mm (1.72 in. x 17.40 in. x
17.49 in.)
Weight
(including
packaging)
8.7 kg (19.2 lb)
Stack ports Not supported
RTC Not supported
RPS Not supported
PoE Supported
Rated voltage
range
● 100 V AC to 130 V AC, 200 V AC to 240 V AC; 50/60 Hz
● High-voltage DC input: 240 V DC
Maximum
voltage range
● 90 V AC to 290 V AC, 45 Hz to 65 Hz
● High-voltage DC input: 190 V DC to 290 V DC
Maximum power
consumption
(100%
throughput, full
speed of fans)
● Without PoE: 75 W
● 100% PoE loads: 911 W (PoE: 874 W)
Typical power
consumption
(30% of trac
load, tested
according to ATIS
standard, with
EEE enabled)
58 W
Operating
temperature
-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m
(0-5906 ft.)
NOTE
When the altitude is 1800-5000 m (5906-16404 ft.), the highest
operating temperature reduces by 1°C (1.8°F) every time the
altitude increases by 220 m (722 ft.).
The equipment cannot start when the temperature is lower than 0°C
(32°F).
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 170
